Wiremaid U.S.A. has just created the "Cable Tray Maker,” an easy-to-use cable tray designer that takes the guess work out of ordering a cable tray system. Click on a cable tray part, choose your options and add the quantity. It creates a bill of materials that you can print or email.

• Requires NO bending or cutting; ready–made 4-way, “T” and “L” shaped junctions

• Conforms to the National Electric Code, UL Classified

• Acts as a continuous ground conductor; no grounding splices

• Adapts to difficult architectural designs to accommodate changes in direction and elevation of cable runs

• Cuts installation time up to 50 percent

• Provides strength, rigidity without additional hardware; has smooth edges

• Manufactured in an array of protective, powder-coated, colored finishes to minimize corrosion

• Featured in light or heavy duty product styles

• All support hardware available

• Powder coating is standard finish

• Custom sizes available

PRO-10 Cable Tray System

M.E.2 Cable Tray CAD drawings

• Factory fabricated junctions save installation time and cut costs.

• Seven or 10 foot length straight tray sections can be cut to length or formed by cutting side wires to change routing elevation at the installation site.

• Two x 4 inch grid provides easy cable routing in or out of tray sections.

• Available metal tray divider for cable separation.

• Rigid steel construction – Made in the USA.

M.E.2 Cable Tray System
